Designed for the intelligent management of fixed and mobile assets, the SmartOne C is a practical solution for a multitude of options including:

• 12 different reporting times
• Interval or 24-hour operation mode
• Alternate reporting scheduling
• Low battery message

How the SmartOne C works:

Tracking

The SmartOne C utilizes motion sensors, comparative GPS positioning and custom configured sensors to gather and transmit information such as movement and location reports, stop/start messaging and theft recovery alerts using Globalstar's regional simplex satellite network. In addition to positional information, the SmartOne C transmits other message types that include battery status, input alarm status and diagnostic information.

Configuration

Each SmartOne C is configured to track its asset's specific needs and provide intermediate and emergency alerts by email and/or text (when used in conjunction with ). The SmartOne C is configured using a computer and USB connection cable and the configuration software offers a wide range of customisable configuration options such as message frequency, movement and motion sensitivity levels and geo-fencing capabilities. This requires the

Messaging

Your tracking device cannot operate without a messaging plan. OSAT offers four subscription plans (Standard Plan, Light Plan, Heavy Plan and Unlimited Plan). Additionally, to receive messages a mapping portal is required.  We offer an add-on OSAT Track service or using your own corporate server is available with a one-off fee. Please note that you must choose one of the mapping options mentioned to receive messages via email.

SmartOne C Key Features:

Global Coverage
With coverage in over 120 countries across the world and many ocean covered areas, the SmartOne can keep you in contact with friends, family and colleagues in areas where mobile phones don’t offer a connection, even in the most remote areas of the world.

Standard Messaging Mode
In Standard Messaging Mode, the SmartOne C reports its GPS position at regular time intervals that are programmed during the initial configuration process. The message interval can be programmed in 1 minute intervals from 35 minutes up to 45 days and messages will be transmitted regardless of whether the asset is moving or stationary. Alternatively, the device can be configured to send messages only when the asset is in motion with messages transmitted from as little as every 5 minutes.

Reduced Messaging Mode
Reduced Messaging Mode reduces the cost associated with transmitting messages over the Globalstar satellite network by sending messages at a minimal message interval when the asset is stationary or in a defined area and transmitting at a higher message interval when the asset is moving or changing locations.

Theft Recovery/ Geo-Fencing Mode
The Theft Recovery mode allows you to configure the device to differentiate between authorized and unauthorized movement of an asset. While the asset remains in an authorised state the SmartOne C will send out infrequent messages. If the SmartOne C detects an unauthorised state, such as movement out of a pre-defined area, it can be configured to send out high frequency messages to enable the unauthorised movement to be monitored closely.

Geo-Fencing
In conjunction with OSAT Track, OSAT’s online mapping portal, the SmartOne satellite asset tracker offers a geo-fencing feature. This allows you to predefine a set of geographical boundaries and be alerted by email when the device enters or exits the geo-fenced area.

Dust & Water Resistant
The SmartOne C satellite asset tracker is designed to withstand the harshest weather conditions.

Customisable tracking
The SmartOne C is an asset tracker that provides customisable, cost-effective monitoring of a wide variety of assets such as cars, trucks, trailers, cargo containers, construction equipment, boats and any other mobile asset.

Portable and Easy to Install
It is easily installed and field managed without the need for harnesses, antennas or external power.

Charging
The SmartOne C Tracker has two options for charging, through an external power supply or 4 "off the shelf" AA 1.5V lithium batteries (included).

By using internal lithium batteries, the SmartOne C is fully portable and can easily be moved from asset to asset and used covertly if required. The device is capable of operating for up to 3 years on internal batteries.

Alternatively, the SmartOne C can be permanently mounted and operated on 10 to 48 Volts DC through an optional line power connection cable. See the accessories tab below to view our and  Cables.

Compatible with Mapping Portals
As Smartone trackers require a mapping portal to receive messages, our OSAT Tracking portal is an ideal service for providing messaging and real-time information via your GPS location. Please note the £8.50 EX.VAT monthly fee for OSAT Track is applicable per device. If you have your own corporate service or mapping portal set-up, our SmartOne plans will accomodate with these services, but with a one-off additional charge.

OSAT Track Professional Mapping
Any person provided with the OSAT Track login can become an operator to monitor any number of GSM or satellite assets simultaneously in-real time and historically on the Professional plan as well as use the other features:

• Notifications and message alerts can be sent directly to the holder of the device via email
• Geo-Fencing capabilities
• Global Tracking
• Multiple layer options and map views
• Inclusive to all devices with GPS tracking capabilities
• Past-tracking data points are always accessible, until the device is de-activated
• Mapping and asset grouping customisation options are available
• Data Reporting and Scheduling functions

SMARTONE SATELLITE TRACKER – MESSAGE DELIVERY OPTIONS AND FORMATS

Before we can activate your SmartOne Satellite Tracker you must select a GTC messaging plan and a message delivery route. The messaging plan allows your SmartOne tracker to transmit its GPS coordinates and other data to your selected destination.

In order to view the GPS coordinates and other information transmitted from the device on a mapping portal, or receive them at a server or by email, you must also select one of the delivery options below:

• GTCTrack
• Deliver raw data to corporate server
• Deliver decoded messages by email
• Deliver decoded messages to a URL

Resources & Downloads
