Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Depth | 0.118" (3mm) |
| Dimensions | 22.5 x 99 x 114 mm |
| Enclosure Rating | IP20 (Terminal), IP40 (Housing) |
| Input Type | Voltage |
| Length | 0.885" (22.5mm) |
| Maximum Operating Temperature | 55 °C |
| Minimum Operating Temperature | -25 °C |
| Mounting Style | DIN Rail |
| Number of Channels | 3 Channel |
| Number of Inputs | 2 |
| Number of Outputs | 3 |
| Number of Poles | 3 |
| Power Rating | 2.5 W |
| Series | |
| Special Features | Fault Diagnosis Function with Dual Safety Circuits |
| Standards | CSA Certified ; TUV NORD ; UL Listed |
| Supply Voltage | 24 VAC/VDC |
| Temperature Operating Range | -10 to 55 C |
| Terminal Type | Plug-In |
| Termination | Plug-In |
| Type | Safety Relay |
| Voltage, Control | 24 VAC ; 24 VDC |
| Width | 3.898" (99mm) |
Overview
HR1S safety control relays are compact units designed to monitor safety input devices, which allow machine operation only when all safety controls are functioning properly and hazardous conditions are not detected. Supported safety devices include E-Stops, interlock switches and non-contact safety switches. These relays have either instantaneous (STOP 0) or time delayed (STOP 1) relay safety outputs, as well as solid-state outputs for use with diagnostics, troubleshooting and correct system operation. In addition, front panel LEDs can be used for monitoring the current status and most models are available in a variety of monitoring configurations, including removable terminals, monitored start, and single- or dual-channel operation.
